PineX Outdoor LoRaWAN Gateway
SKU#
PINEX
Replaced by
Replaced SKU
PineX is an industrial-grade outdoor LoRaWAN® Gateway, designed to operate reliably in the harshest environments—from scorching deserts to freezing Arctic conditions, and even hurricane-force winds up to 200 km/h. With IP67-rated waterproof and dustproof protection, an extended temperature range of -40°C to +70°C, and Dual LoRa Antennas for extended coverage, PineX ensures uninterrupted, long-range connectivity even in extreme weather conditions. Supporting all global LoRaWAN frequency bands, PineX integrates a built-in Network Server, Node-RED, and VPN security, enabling fast, cost-efficient, and secure IoT deployments. Its integrated 4G Router with PoE (802.3at) support allows for seamless Internet access and power supply for IP cameras, sensors, and other connected devices. Designed for Smart Cities, Industrial Facilities, Smart Agriculture, and remote IoT applications, PineX is the ultimate rugged, high-performance LoRaWAN Gateway for mission-critical operations.
Applications
Condition Based Monitoring, Energy Monitoring, Facility Monitoring, Fuel Monitoring, Gas Leakage Detection, Machine Health Monitoring, Production Monitoring, Temperature Monitoring, Vibration Monitoring, Warehouse Monitoring, Water Meter Reading
Connect to any LoRaWAN sensors
Compliance to LoRaWAN 1.0.3
Rugged design for extreme working environment
Anodized aluminum durable compact housing for extreme working condition such as 200 km/h wind speed, -40 to 70 oC, chemical gas and salty environment
Versatile built-in functions
VPN function for remote support, built-in Network Server and Node-RED for simplified setup and reduced cost, 4G router & POE source for another device
Multi-option for various applications
Cellular/Wifi connection, dual/single standard/SMA antenna, GPS/no GPS, Ethernet port with/without POE source
.
| LoRaWAN Specification | LoRaWAN 1.0.3 |
| Frequency Band | Select 863∼870MHz or 902∼928MHz |
| Number of Channels | Up to 8 concurrent channels for LoRa transmission |
| LoRa Transmit Power | 0.5W (up to 27 dBm) |
| LoRa Receive Sensitivity | Down to -139dBm@SF12, BW 125 kHz. |
| LoRa Software | Package Forwarder |
| Advanced Software features | OpenVPN, built-in LoRaWAN Network Server & Node-RED, Cellular Internet Routing function, low-power, robust, aesthetic design |
| COMMUNICATION | |
| Standard Host Communication | Ethernet 100Mbps, via outdoor RJ45 connector |
| Optional External Cellular Module | LTE Cat 4, supports multi-region and global bands as below |
| Frequency Bands for AU: LTE-FDD (B1/2/3/4/5/7/8/28) LTE-TDD (B40) | |
| Frequency Bands for EU: LTE-FDD (B1/3/7/8/20/28A) LTE-TDD (B38/40/41) | |
| Frequency Bands for A: LTE-FDD (B2/4/12) | |
| Frequency Bands for Global: LTE-FDD (B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28) LTE-TDD (B38/39/40/41) | |
| Optional GPS | GPS + GLONASS |
| Antenna Type | Single/Dual LoRa antenna, optional 4G LTE internal/external antenna |
| Power supply | 12-24VDC via M12 port |
| Ethernet port | support PoE+ source 802.3at |
| Housing | Anodized Aluminum, IP67, can withstand Wind speeds up to 200 Km/h |
| Working temperature | -40 to 70 oC |
| Dimensions | Diameter of 70 mm, H:500 mm (include antenna) |
| Weight | < 2.0kg |
Dimension
Notes
