Sigfox Gas Detecting Sensor
SKU#
WSSFC-G4
Replaced by
Replaced SKU
WSSFC-G4 is a Sigfox-ready electrochemical-type gas sensor with a high sensitivity to low concentrations of detected gas, high selectivity, and a stable baseline. The device supports different types of gas such as CO, NO, NO₂, H₂S, NH₃, O₂, O₃, SO₂, Cl₂, HCHO... With ultra-low-power design and smart firmware allow the complete Wireless and Sensor package run on 2 x AA battery 1.5V for 5-10 years (depend on configuration). It supports all regions of the Sigfox network over the World RC1, RC2, RC3, RC4, RC5, RC6, and RC7. Typical Applications are Gas, toxic gas detecting, air quality monitoring for facility, building, pump station, HVAC...
For Applications
Ambient Air Quality Monitor, Indoor Air Quality Monitor, Gas Analyzing, Warehouse Monitoring, Gas Leakage Detection
Sigfox-Ready
Device are best operating performance on the SIGFOX network
High Accuracy & Stable
Advanced electrochemical-type gas sensor technology processing to deliver high accuracy and stable measurement
5-10 years battery
Ultra-low power sensing technology from Daviteq with Ultra-low power wireless technology allow the sensor can last up to 5-10 years with 02 x AA batteries
Multiple choices of gas
| Select gas sensor | CO, NO, NO₂, H₂S, NH₃, O₂, O₃, SO₂, Cl₂, HCHO etc. |
| Gas sensor type and specification | List of compatible gas sensors and specification |
| Sensor housing/ Rating | SS316/SS304 housing with 316SS sintered filter/ for Indoor use (buy the optional accessory rain-guard for outdoor installation) |
| COMMUNICATION | |
| Sigfox zones | RC1∼RC7 |
| Antenna | Internal Antenna 2.0 dbi |
| Battery | 02 x AA size 1.5VDC, battery not included |
| Data sending modes | Interval time and when alarm occurred |
| Configuration | via Downlink or Offline cable (software is free) |
| RF Module complies to | ETSI EN 300 220, EN 303 204 (Europe) FCC CFR47 Part15 (US), ARIB STD-T108 (Japan) |
| Working temperature | -40∼60℃ (with AA L91 Energizer®) |
| Housing/ Protection | Aluminum + Polycarbonate/ IP67 |
| Dimension/ Net weight | H180xW73xD4/ < 400grams |
Dimension
WSLRW-G4-H7 LoRaWAN Gas Detecting Sensor WSLRW-G4.jpg
WSLRW-G4-H7 LoRaWAN Gas Detecting Sensor WSLRW-G4.jpg
1/1
Application Notes
Select the suitable sensor range to get the highest accuracy vs. sensor life.
Lifetime is 1-2 years, depending on sensor type and actual operating conditions.
Need to be calibrated regularly (6-12 months), depending on actual operating conditions.
Check carefully the working temperature and humidity of the application.
Use the Rain-guard or Splash-guard for outdoor installation or where water jets exist.
Lifetime is 1-2 years, depending on sensor type and actual operating conditions.
Need to be calibrated regularly (6-12 months), depending on actual operating conditions.
Check carefully the working temperature and humidity of the application.
Use the Rain-guard or Splash-guard for outdoor installation or where water jets exist.
