Sigfox Node with RS485 Master Port
SKU#
WSSFC-MB485
Replaced by
Replaced SKU
WSSFC-MB is a Sigfox-ready node with an RS485 master port to connect to any sensor, water meter, power meter, gas meter, or flow computer... With an RS485 slave port. The device supports different fieldbus protocols like Modbus RTU, Modbus ASCII, DLMS Cosem, and Mbus...The device is configurable via offline software and downlink messages. Ultra-low-power design and smart firmware allow the sensor to run on a 2 x AA battery 1.5V for 10 years with one update per day. It can support Sigfox Zones RC1, RC2, RC3, RC4, RC5, RC6, and RC7.
For Applications
Electric Meter Reading, Gas Meter Reading, Water Meter Reading, Production Monitoring, Facility Monitoring
Sigfox Ready
Device are best operating performance on the SIGFOX network
10-Year battery
Ultra-low power sensing technology from Daviteq with Ultra-low power wireless technology allow the sensor can last up to 10 years with 02 x Type AA batteries.
Support various Fieldbus Protocols
Support Modbus RTU, Modbus ASCII, DLMS Cosem...
IP68
For both indoor and outdoor applications
| Input port | 1 x RS485 master port |
| Cable length | 2m, shielded cable with marking A & B wires |
| Protocol | Select Modbus RTU, Modbus ASCII, DLMS Cosem, Mbus etc. (Contact us before ordering) |
| Fault protected RS-485 bus pins | up to ±40V |
| HBM ESD protection on RS-485 bus pins | ±15kV |
| Extened common mode range | ±15V (larger than required for RS-485) |
| High transient over voltage tolerance | ±60V |
| Full fail-safe RS-485 receivers | open, short, terminated |
| COMMUNICATION | |
| Sigfox zones | configurable RC1-RC2-RC3a-RC3c-RC4-RC5-RC6-RC7 |
| Sigfox Class | 1u |
| Functions | Sending data in interval or when alarms occur |
| Antenna | Internal Antenna 2 dbi |
| Configuration | via Downlink of offline USB cable (PC software is supplied at free) |
| Electrical connection | Shielded cable 2m length with PG9 cable gland |
| Power Supply | Primary batteries 02 x AA size 1.5VDC (battery not included) for Battery-powered version, 7-48VDC for external DC powered version. |
| RF Module complies to | ETSI EN 300 220, EN 303 204 (Europe) FCC CFR47 Part15 (US), ARIB STD-T108 (Japan) |
| Device Certification | CE, FCC (on demand) |
| Working temperature | -40∼60℃ (with AA L91 Energizer®) |
| Dimensions | H106xW73xD42 |
| Net-weight | <180g |
| Housing | Polycarbonate plastic, IP68 |
| Mounting | Wall mount |
Dimension
WSSFC-MB485- Daviteq Sigfox RS485 Modbus Node - H6.jpg
WSSFC-MB485- Daviteq Sigfox RS485 Modbus Node - H6.jpg
1/1
